- High-concerned chemical: None
- Zoom type: None
- Zoom: None
- Lens Quantity: Dual Lens
- AI Functions: Motion Detection
- Color Night Vision: Yes
- Operating Temperature: -10°-60°
- IP Rating: IP67
- App name: Other
- Rechargeable Battery: None
- Scene: Indoor and outdoor
- Movement Range(Tilt): -10°-180°
- Movement Range(Pan): -10°-180°
- Megapixels: 8MP
- TF Card: None
- Power Supply: With Poe
- Internal Storage: 256GB
- Installation: Side
- Color: WHITE
- is_customized: Yes
- Audio Output: 1CH BNC
- Minimum Illumination(Lux): 2X1/2.5 Progressive Scan CMOS
- Viewing Angle : 180 °
- Video Compression Format: H.265
- IR Distance(m): IR light up to 30m
- Power Supply(V): 12 V DC
- Power Consumption(W): 12W
- Supported Mobile Systems: Android,iOS
- Sensor Brand: Sony
- Sensor: CMOS
- Model Number: I91ET/I51HD
- Supported Operating Systems: Windows 98,Windows XP,Windows Vista,Windows 7,macOS,Windows 8,Windows 10,Windows 2000,Windows 2008,Windows 2003
- Lens (mm): 2.8mm
- Connectivity: IP/Network Wired
- High Definition: 8.0 Megapixels
- Style: Bullet Camera
- Brand Name: ANNKE
- Origin: Mainland China
- Special Features: Waterproof / Weatherproof
- Certification: CE
- Alarm Type: Local Alarm
- Shell Material: Plastic
- Smart home platform: None
- Optical Zoom: None
I51DX/I91DX camera only work with “ANNKE” NVR and should be updated to the latest version.
(Please confirm if your NVR is the latest version before you purchase this camera.)
8MP Key features
★ High quality imaging with 8 MP resolution
★ One image that presents all the scenes covered by the camera
★ Provide real-time security via built-in two-way audio
★ Efficient H.265+ compression technology
★ Focus on human and vehicle classification based on deep learning
★ Clear imaging against strong back light due to 120 dB WDR technology
★ Active strobe light and audio alarm to warn intruders off
★ Smart Hybrid Light: White light & IR light up to 30 m
★ Support 512 GB TF storage space
★ Water and dust resistant (IP67)
Packaging Contents
1XIP Camera
1XSurveillance Sign
1X1m Network cable
1XWaterproof connector
1XMounting Screws Bag
1XUser’s Manual For Camera
| Model Number | I91ET 8MP | |
| IP Camera | ||
| Camera | Image sensor | 2×1/2.4″ Progressive Scan CMOS |
| Max resolution | 4096 x 1860 | |
| Main Stream | 50 Hz: 20 fps (4096 x 1860) 60 Hz: 20 fps (4096 x 1860) | |
| Sub Stream | 50 Hz：20 fps（1200 × 536, 960 × 432） 60 Hz：20 fps（1200 × 536,960 × 432） | |
| Video compression | Main Stream: H.265+/H.265/H.264+/H.264 Sub Stream: H.265/H.264/MJPEG | |
| Video Bit Rate | 32 Kbps to 16 Mbps | |
| Built-in Microphone | Built-in Microphone, record with audio | |
| Audio Compression | G.711/G.722.1/G.726/MP2L2/PCM/AAC-LC | |
| Built-in Speaker | Yes, max. sound pressure: 10 cm: 97 dB | |
| Lens | Dual lens: 2 mm | |
| Min. Illumination | Color: 0.005 Lux @ (F1.6, AGC ON) | |
| Angle of View | Horizontal FOV: 180°, Vertical FOV: 77° | |
| Supplement Light Type | Smart light, white light, IR light | |
| Supplement Light Range | White light up to 30 m, IR light up to 30m | |
| Motion detection 2.0 | Supoort, include human & vehicle detection | |
| Image Parameters Switch | Yes | |
| Image Enhancement | BLC, HLC, 3D DNR | |
| Wide Dynamic Range | 120dB WDR | |
| Network Protocols | TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, RTCP, NTP, IPV4, IPV6, IGMP, UDP, QoS, FTP, SMTP | |
| API | Support Open Network Video Interface protocol, version 19.12 | |
| Basic Event | Motion detection (support human and vehicle detection), video tampering, exception detection | |
| Audio Alarm | Support(Parameters adjustable,support custom audio, can be triggered from APP) | |
| Flashing Alarm | White light, frequency adjustable, can be triggered from APP | |
| Region of Interest (ROI) | 1 fixed region for main stream | |
| Privacy Mask | 4 programmable polygon privacy masks | |
| General Function | Rotate, remote access, IP Address Filter | |
| General | Housing | Metal&Plastic, white color |
| Operating Power | PoE (802.3af)，max 11.5W, 12 VDC ± 25%,Ø 5.5 mm coaxial power plug, max 10W | |
| Ethernet Interface | 1 RJ45 10 M/100 M self-adaptive Ethernet port | |
| Storage | Built-in micro SD/SDHC/SDXC slot, up to 512 GB | |
| Hardware Reset | Yes | |
| Operating Temperature | -22 °F – 140 °F /-30 °C – 60 °C | |
| Indoor/Outdoor | Indoor/Outdoor | |
| Weatherproof Rating | IP67 | |
| Dimension (L x W x H) | Ø 130.1 mm × 109.1 mm (Ø 5.1″ × 4.3″) | |
| Weight | Approx. 586 g (1.3 lb.) | |
| Model Number | I51HD 6MP | |
| IP Camera | ||
| Camera | Image sensor | 2×1/2.5″ Progressive Scan CMOS |
| Max resolution | 3632 × 1632 | |
| Main Stream | 50 Hz: 20 fps (3632 × 1632) 60 Hz: 20 fps (3632 × 1632) | |
| Sub Stream | 50 Hz：20 fps（1200 × 536, 960 × 432） 60 Hz：20 fps（1200 × 536,960 × 432） | |
| Video compression | Main Stream: H.265+/H.265/H.264+/H.264 Sub Stream: H.265/H.264/MJPEG | |
| Video Bit Rate | 32 Kbps to 16 Mbps | |
| Built-in Microphone | Built-in Microphone, record with audio | |
| Audio Compression | G.711/G.722.1/G.726/MP2L2/PCM/AAC-LC | |
| Built-in Speaker | Yes, max. sound pressure: 10 cm: 97 dB | |
| Lens | Dual lens: 2.8 mm | |
| Min. Illumination | Color: 0.005 Lux @ (F1.6, AGC ON) | |
| Angle of View | Horizontal FOV: 180°, Vertical FOV: 77° | |
| Supplement Light Type | Smart light, white light, IR light | |
| Supplement Light Range | White light up to 30 m, IR light up to 30m | |
| Motion detection 2.0 | Supoort, include human & vehicle detection | |
| Image Parameters Switch | Yes | |
| Image Enhancement | BLC, HLC, 3D DNR | |
| Wide Dynamic Range | 120dB WDR | |
| Network Protocols | TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, RTCP, NTP, IPV4, IPV6, IGMP, UDP, QoS, FTP, SMTP | |
| API | Support Open Network Video Interface protocol, version 19.12 | |
| Basic Event | Motion detection (support human and vehicle detection), video tampering, exception detection | |
| Audio Alarm | Support, parameters adjustable,support custom audio, can be triggered from APP | |
| Flashing Alarm | White light, frequency adjustable, can be triggered from APP | |
| Region of Interest (ROI) | 1 fixed region for main stream | |
| Privacy Mask | 4 programmable polygon privacy masks | |
| General Function | Rotate, remote access, IP Address Filter | |
| General | Housing | Metal&Plastic, white color |
| Operating Power | PoE (802.3af)，max 11.5W, 12 VDC ± 25%,Ø 5.5 mm coaxial power plug, max 10W | |
| Ethernet Interface | 1 RJ45 10 M/100 M self-adaptive Ethernet port | |
| Storage | Built-in micro SD/SDHC/SDXC slot, up to 512 GB | |
| Hardware Reset | Yes | |
| Operating Temperature | -22 °F – 140 °F /-30 °C – 60 °C | |
| Indoor/Outdoor | Indoor/Outdoor | |
| Weatherproof Rating | IP67 | |
| Dimension (L x W x H) | Ø 130.1 mm × 109.1 mm (Ø 5.1″ × 4.3″) | |
| Weight | Approx. 580 g (1.3 lb.) | |
